ZYX R50-BLOOM EX

Type Moving Coil (Dynamic)

“REAL STEREO” Generator System

Output Voltage 0.24mV (0.48mV) (3.54cm/sec, 1kHz)

Frequency Response

±1dB 10 Hz - 40 kHz

20 Hz - 20 kHz

Channel Separation ＞ 25dB 〔 1kHz 〕

Channel Balance ＜ 0.5dB 〔 1kHz 〕

Recommended Tracking Force 2.0gm 〔 20 ゜C-25 ゜C 〕

Tracking Force Range 1.7gm - 3.0gm

Trackablity ＞ 60μm

EQ Compliance horizontal

  vertical

15×10-6cm/dyne

12×10-6cm/dyne

Internal Impedance 4.0 Ω (8.0 Ω)

Load Impedance ＞ 100Ω

Coil Wire 6N Copper Wire φ0.03mm

Cantilever Material black ALM g5 tube φ0.38/ φ0.3mm

Stylus Line-contact Solid Diamond □ 0.1mm

Contact Radius, Life Time 6μm×60μm, 2000Hour/2.0gm

Output Terminals φ1.25mm gold plated 〔 EIA 〕

Terminal Board Glass Epoxy Plate

Dimensions W (Width) : 16.3mm

L (Length) Body / with Terminals : 19.6mm / 23.5mm

H (Height) : 15.5mm

Net Weight 5.0gm
